Cast iron gate valve with bellows - KP-821

Cast iron gate valve with bellows | KP-821

Cast iron gate valve with bellows | KP-821
Cast iron gate valve with bellows | KP-821
gallery slider left
gallery slider right

Flange connection PN 16

Suitable for: cold and hot water, steam, hydrocarbons, gas and air

  • Maintenance-free.
  • Very good protection against atmospheric leakage.
  • Durable in use.
Specifications
Cast iron gate valve with bellows | KP-821
Cast iron gate valve with bellows | KP-821
Previous series Next Series

Specifications

Type KP-821
Material Cast Iron GJL-250
Pressure class PN 16
Top part Cast Iron GJL-250
Handwheel Nodular cast iron
Seat Stainless steel X20Cr13
Disc Stainless steel X5CrNi18-10
Spindle Stainless steel X20Cr13
Bellows Stainless steel X5CrNi18-10
Cover gasket Graphite
Gland packing Graphite
Face to face EN558-1 series 1
Connection EN1092-2
Temperature -10°C to +300°C
