Nodular Cast Iron Tomoe Butterfly Valve for Food | KP-1062 SEP
Wafer lug type with threaded bolt holes and replaceable patented SEP rubber seat profile.
Suitable for: food applications, food and pharmacy
- Meets the requirements of EC1935/2004 and is FDA approved.
- Wafer lug type with threaded holes for flanges PN10 or PN16 or ANSI 150#.
- Low operating torque, perfect sealing and long lifetime due to cosine curve seat.
- High Kv value due to pantented cosine curve seat, large bore diameter and profiled disc.
- Excellent leaktight sealing perfomance.
- Equipped with top flange according to ISO 5211 for easy mounting with an actuator.
- Tomoe Series 704G (DN40-DN300).
Urgency or questions about availability?
blade smooth polished "mirror finish " or equipped with Viwateq® protection for sticky media such as powders or where frequent cleaning is not done to prevent bacterial growth
also available: smaller sizes with reduction gearbox
also available: smaller sizes with reduction gearbox
Specifications
| Type | KP-1062 SEP |
| Material | Nodular Cast Iron EN-GJS-450-10 (with epoxy coating) |
| Pressure class | PN16 DN50 to DN200 |
| PN10 DN250 and DN300 | |
| larger dimensions on request | |
| Disc | STAINLESS STEEL EN 10213-4 (AISI 316) |
| Shaft | STAINLESS STEEL EN 10088-3 |
| Seat | SEP white rubber ( Silicon Ethylene Propylene) |
| Handle | ductile iron |
| Gearbox | Cast iron, stainless steel shaft and cast iron handwheel |
| Face to face | EN 558-1 series 20 |
| Connection | DN40 to DN150 DIN PN10/16 or ANSI 150# |
| DN200 to DN300 DIN PN10 or PN16 or ANSI 150# | |
| Flow rate | Liquid up to 3m/sec |
|
|
|
| Temperature | Continuous -10 to 80ºC |
| suitable for frequent cleaning with hot water and low-pressure steam | |
Contact
For more information about our Tomoe butterfly valves for control application, please contact us at:
