Cast iron air coupling | SSGA
External thread connection adjustable coupling
Suitable for: compressed air
- Half-Quick release couplings, fitted with claws and easy to couple. Two lip seals (one in each of the two couplings), located in a seat, provide the seal.
- Mody: with adjustable coupling.
Urgency or questions about availability?
Specifications
| Type | SSGA |
| Material | Galvanized cast iron (chrome - VI - free) |
| Sealing ring | Nitrile |
| Ridge distance | 42 mm |
|
|
|
| Max. working pressure | 16 bar |
| Temperature | -40ºC to +95ºC |
| Execution | according to DIN 3238 |
| Option | special sealing rings 200ºC |
