Bronze temperature regulator - OB-30/31

Bronze temperature regulator| OB-30/31

product image
product image
product image
Bronze temperature regulator| OB-30/31
Bronze temperature regulator| OB-30/31
Bronze temperature regulator| OB-30/31
gallery slider left
gallery slider right

Threaded connection BSPT

Suitable for: steam, air and non-corrosive liquids

  • Direct acting, no auxiliary energy needed.
  • Wide temperature range.
  • For heating or cooling.
Specifications
Bronze temperature regulator| OB-30/31
Bronze temperature regulator| OB-30/31
Bronze temperature regulator| OB-30/31

Urgency or questions about availability?

Pressure, Regulator & Safety Devices
088 528 20 81
or

Specifications

Type OB-30/31
Material Bronze
Seat AISI 304 STAINLESS STEEL
Disc PTFE
Capilary Stainless steel AISI 304 sheathed, length 5 meters
Probe Copper nickel plated
Immersion tube AISI 304 STAINLESS STEEL
Maximum pressure differential 10bar
Control accuracy +/- 4ºC
Working pressure max. 10/16 bar
Connection BSPT thread
Temperature maximum 185ºC
Contact

For more information about our pressure reducing devices, temperature regulators, and safety valves, please contact us at:
