Brass free-flow check valve | KP-540
Threaded connection BSP, spring loaded valve (lift)
Suitable for: water, steam, condensate and non-aggressive liquids
- Can be mounted horizontally and vertically.
- Spring-loaded valve.
Urgency or questions about availability?
Specifications
| Type | KP-540 |
| Material | Brass CuZn40Pb2 |
| Pressure class | PN 16 |
| House | Brass |
| Valve Ring | FKM |
|
|
|
| Connection | BSP female thread |
|
|
|
| Temperature | max 200º at 12 bar |
| max 150º at 32 bar | |
