Steel spring-loaded check valve | KP-5509
Flange connection PN40
Suitable for: steam, water, oil and non-aggressive liquids
- For horizontal or vertical mounting.
Specifications
| Type | KP-5509 |
| Material | Cast steel GP240GH+N |
| Pressure class | PN 40 |
| Disc | stainless steel 13%Cr |
| Seat | RVS 316 |
| Spring | stainless steel 13%Cr |
|
|
|
| Face to face | EN558-1 series 1 |
| Connection | Flange connection PN40 EN1092-1 B1 |
|
|
|
| Temperature | -10ºC to max +400ºC at 21 bar |
| _______ max +200ºC at 35 bar | |
| _______ max +120ºC at 40 bar | |
