Steel Armstrong thermodynamic steam trap | CD-72S

Suitable for: dewatering and process applications

Type	CD-72S
Material	Steel ASTM A105N / A350 LF2 Cl. 1
Disc	ASTM A276 Gr. 420
Seat	17-4 PH
Working pressure max.	41 bar
Working pressure min.	0.24 bar
Design pressure	70 bar / 400ºC

Connections	BSPT or NPT thread, SW and EN or ANSI flange

Temperature	Max. 400ºC

Contact

For more information about our condensate systems, please contact us at:

appendages@klinger.nl

Specifications
