Stainless steel Armstrong thermostatic bimetallic steam trap | SH-900L / H
with integrated filter
Suitable for: dewatering of superheated steam
- Discharges condensate below saturated steam temperature.
- Has very high venting capacity during startup.
- Can also be used as an air vent.
- Coated bi-metal for reduced dirt adhesion.
- Titanium valve and seat for longer service life.
Specifications
| Type | SH-900L / H |
| Material | STAINLESS STEEL ASTM A351-GR CF8M |
| Disc | Titanium |
| Seat | Titanium |
| Bi-metal elements | Nickel-Chrome and stainless steel |
| Maximum back pressure | 99% of the inlet pressure |
|
|
|
| Working pressure max. | SH-900L 17 to 44 bar |
| SH-900H 41 to 62 bar | |
|
|
|
| Connections | BSPT or NPT thread, weld (SW and BW) and ANSI flange |
| Temperature | max. 482ºC |
