Armstrong stainless steel inverted bucket steam trap | 1800 Series
with horizontal connection
Suitable for: dewatering, tracing and process applications
- Discharges condensate directly, no condensate back up.
- Maintenance-free and not sensitive to dirt.
- Resistant to water hammer.
- Frost Resistant.
Also available
- available in PN100 model
- available in ANSI 600# model
Specifications
| Type | 1800 Series |
| Material | RVS 304L |
|
|
|
| Internals | RVS 304L |
| Valve and seat | hardened chrome steel 17-4-PH |
| Flanges | (if applicable) steel PN40 max. 32 bar @250ºC, optional stainless steel |
| Working pressure max. | type 1810 14 bar |
| type 1811 28 bar | |
| type 1822 45 bar | |
| Backpressure | up to 99% of inlet pressure |
|
|
|
| Connections | BSP or NPT thread, weld connection,flanges DIN or ANSI |
|
|
|
| Temperature | max. 427ºC |
|
|
|
| Also available | different valve passage |
| insupak insulation for the 1810 and 1811 | |
| "Pop-drain" automatic drain for the 1811 and 1822 | |
| other connections | |
Contact
For more information on our inverted bucket steam traps, please contact us at:
