forged steel Armstrong inverted bucket steam trap | EM
With horizontal installation.
Suitable for: dewatering, tracing and process applications
- Steam trap can be opened for repair.
- Discharges condensate directly, no condensate back up.
- Maintenance-free and not sensitive to dirt.
- Resistant to water hammer.
Urgency or questions about availability?
Specifications
| Type | EM |
| Material | Forged steel. |
|
|
|
| Top part | Steel (optional in stainless steel) |
| Internals | RVS 304 |
| Valve and seat | hardened chrome steel 440F |
| Bolts | 24CrMo5 |
| Cover gasket | Graphite |
| Working pressure max. | 32 bar |
| Backpressure | up to 99% of inlet pressure |
|
|
|
| Connections | BSP or NPT thread,socket weld, and DIN or ANSI flange connection |
|
|
|
| Temperature | Max. 250ºC |
|
|
|
| Also available | Different valve passages |
| Seat of stellite or titanium in the case of superheated steam | |
Contact
For more information on our inverted bucket steam traps, please contact us at:
