Bronze gate valve with wear-resistant valve | KP-530
Flange connection, PN 16
Suitable for: steam, water, oil, gases and air
Specifications
| Type | KP-530 |
| Material | Bronze CuSn5Zn5Pb5-C |
| Pressure class | PN 16 |
| Top part | Bronze CuZn40Pb2 |
| Handwheel | Aluminum |
| Seat | AISI 316 STAINLESS STEEL |
| Disc | AISI 316 STAINLESS STEEL |
| Spindle | Bronze CuZn39Pb3 |
| Gland packing | PTFE, as of 3/4" AF/15/MA |
|
|
|
| Temperature | 7 bar to 170°C |
| 16 bar up to 100°C | |
