Steel gate valve | KP-772
Flange connection PN 40
Suitable for: cold and hot water, oil and steam plants
- Manufacturer PERSTA-200AE
Options
- with control valve
- With adjustable flap and seat
- with welding ends
- pressure class PN63 and PN160
Specifications
| Type | KP-772 |
| Material |
DN15-50_ Forged steel P250GH DN65-200 Cast steel GP240NH |
| Pressure class | PN 40 |
| Top part | DN15-50_ Forged steel P250GH |
| DN65-200 Cast steel GP240GH+N | |
| Handwheel | EN-GJS-400-15 |
| Threaded canister | Bronze |
| Seat | Stainless steel, welded |
| Disc | Stainless steel X 20Cr 13 |
| Spindle | Stainless steel X20Cr13 |
| Cover gasket | Graphite |
| Gland packing | Graphite |
|
|
|
| Face to face | EN558-1 series1 |
| Connection | EN1092-1 |
|
|
|
| Temperature | -20°C to +400°C |
