Cast Iron KLINGER KVMn Piston valve | KP-123

Cast Iron KLINGER KVMn Piston valve | KP-123
Cast Iron KLINGER KVMn Piston valve | KP-123
gallery slider left
gallery slider right

Threaded connection BSP

Suitable for: steam, condensate, water, oil, air and gas

  • By default, the valve already has control characteristics.
  • Universally applicable (steam, oil, water, gas), one type of rings for all media except highly oxidizing acids.
  • Simple and inexpensive revision, can be repeated many times.
  • Can be overhauled in the pipe.
  • High Kv value.
Specifications
Downloads
Cast Iron KLINGER KVMn Piston valve | KP-123
Cast Iron KLINGER KVMn Piston valve | KP-123
Previous series Next Series

Specifications

Type KP-123
Material Cast Iron EN-GJL-250
Pressure class PN 16
Top part Cast Iron EN-GJL-250
Handwheel Cast Iron EN-GJL-200
Spindle Stainless steel X20Cr13
piston Stainless steel X14CrMoS17
Seal KLINGER KX module
Connection EN 1226-1 (BSP)
Temperature -10°C to +300°C
